NCCL源码解析⑥:Channel搜索

原创
08/18 08:20
阅读数 306



作者|KIDGINBROOK
更新|潘丽晨


上节讲到已经计算出GPU和NIC节点到其他任意节点的最优路径了,本节看下NCCL中channel的搜索过程。


NCCL中channel的概念表示一个通信路径,为了更好地利用带宽和网卡,以及同一块数据可以通过多个channel并发通信,另外后续可以看到一个channel对应了一个GPU SM,所以基于这些原因,NCCL会使用多channel,搜索的过程就是搜索出来一组channel。



如上节所述,单机的情况下会在ncclTopoTrimSystem函数里删除网卡,因此我们先看下单机八卡这种简化的情况,最后再看下多机引入网卡之后的情况。


static float getMaxWidth(struct ncclTopoSystem* system, struct ncclTopoNode* gpu, int type) {  float maxWidth = 0.0;  for (int i=0; i<system->nodes[type].count; i++) {    struct ncclTopoLinkList* path = gpu->paths[type]+i;    float width = path->width;    if (path->count == 0) continue;    maxWidth = std::max(maxWidth, width);  }  return maxWidth;}  ncclResult_t ncclTopoSearchInit(struct ncclTopoSystem* system) {  system->maxWidth = 0.0;  int inter = system->nodes[NET].count;  if (inter == 0 && system->nodes[GPU].count == 1) {    system->maxWidth = LOC_WIDTH;    return ncclSuccess;  }  for (int g=0; g<system->nodes[GPU].count; g++) {    struct ncclTopoNode* gpu = system->nodes[GPU].nodes+g;    system->maxWidth = std::max(system->maxWidth, getMaxWidth(system, gpu, inter ? NET : GPU));  }  return ncclSuccess;}


ncclTopoSearchInit就是初始化system->maxWidth,如果是单机单卡的情况,那么maxWidth设置为LOC_WIDTH,否则就遍历每个GPU节点,查看到其他所有GPU节点或者网卡最大带宽。


  struct ncclTopoGraph ringGraph;  ringGraph.id = 0;  ringGraph.pattern = NCCL_TOPO_PATTERN_RING;  ringGraph.crossNic = ncclParamCrossNic();  ringGraph.collNet = 0;  ringGraph.minChannels = 1;  ringGraph.maxChannels = MAXCHANNELS/2;  NCCLCHECK(ncclTopoCompute(comm->topo, &ringGraph));  NCCLCHECK(ncclTopoPrintGraph(comm->topo, &ringGraph));


nccl执行集合通信时支持ring,tree和collnet三种算法,这里我们以ring来举例,后续专门介绍ring和tree。


struct ncclTopoGraph {  // Input / output  int id; // ring : 0, tree : 1, collnet : 2  int pattern;  int crossNic;  int collNet;  int minChannels;  int maxChannels;  // Output  int nChannels;      // 搜索到的channel数量  float speedIntra;   // 节点内单个channel带宽  float speedInter;   // 节点间单个channel带宽  int typeIntra;      // 节点内channel的路径类型  int typeInter;      // 节点间channel的路径类型  int sameChannels;   // channel是否一样  int nHops;  int intra[MAXCHANNELS*NCCL_TOPO_MAX_NODES];  // 节点内每个channel路径  int inter[MAXCHANNELS*2];                    // 节点间每个channel路径};


ncclTopoGraph记录了搜索到的结果,具体含义见注释。



然后看下ncclTopoCompute,这里就是实际搜索channel的过程,目标是搜索出来尽可能多,带宽尽可能大的一系列channel,本质就是暴力搜索,先设置一系列的条件搜答案,如果搜不出来则降低条件继续搜。



由于此时没有NET节点,所以crossNic为0,然后初始化graph,首先设置最高的条件,限制节点内部只能使用不超过PATH_NVL路径,节点间只能使用不超过PATH_PIX的路径,然后通过system-maxWidth设置speedIntra和speedInter,接着执行ncclTopoSearchRec搜索出一个答案存储到tmpGraph中。



如果此时就是最优的结果,channel数等于maxChannel,并且speedInter也等于maxWidth,则直接退出,否则就开始逐步降低条件,比如将sameChannel设置为0,允许channel之间不一样;调大typeIntra和typeInter;允许crossNic;调小speedInter和speedIntra。


ncclResult_t ncclTopoCompute(ncclTopoSystem* system, struct ncclTopoGraph* graph) {  int ngpus = system->nodes[GPU].count;  int crossNic = (system->nodes[NET].count > 1) && graph->crossNic ? 1 : 0;  graph->speedIntra = graph->speedInter = 0;  if (graph->crossNic == 2) graph->crossNic = 0;  graph->typeIntra = ngpus == 1 ? PATH_LOC : PATH_NVL;  graph->typeInter = PATH_PIX;  graph->nChannels = 0;  graph->sameChannels = 1;    if (ngpus == 1) if (graph->pattern != NCCL_TOPO_PATTERN_RING) graph->pattern = NCCL_TOPO_PATTERN_TREE;   struct ncclTopoGraph tmpGraph;  memcpy(&tmpGraph, graph, sizeof(struct ncclTopoGraph));   // First try crossnic, then decrease speed and finally increase speedIntra.  tmpGraph.pattern = graph->pattern;  int pass = 1;  int speedIndex = 0;  while (speedArray[speedIndex] > system->maxWidth && speedIndex < NSPEEDS-1) speedIndex++;  tmpGraph.speedIntra = tmpGraph.speedInter = speedArray[speedIndex];  int64_t globalTimeout = NCCL_SEARCH_GLOBAL_TIMEOUT; search:  int time = tmpGraph.sameChannels ? NCCL_SEARCH_TIMEOUT_SAMECHANNELS :    tmpGraph.pattern == NCCL_TOPO_PATTERN_TREE ? NCCL_SEARCH_TIMEOUT_TREE : NCCL_SEARCH_TIMEOUT;  tmpGraph.nChannels = 0;  globalTimeout -= time;   NCCLCHECK(ncclTopoSearchRec(system, &tmpGraph, graph, &time));   // Optimal solution, stop here  if (graph->nChannels == graph->maxChannels && graph->speedInter == system->maxWidth) goto done;   if (pass == 1) {    // First pass, we don't have a solution yet ; try other options     // Try having different channels    if (tmpGraph.sameChannels == 1) {      tmpGraph.sameChannels = 0;      goto search;    }    tmpGraph.sameChannels = 1;     if (time != -1) globalTimeout += time;    else globalTimeout = NCCL_SEARCH_GLOBAL_TIMEOUT;    if (globalTimeout < 0) goto done;     int maxTypeIntra = system->nodes[NET].count > 0 ? tmpGraph.typeInter : PATH_SYS;    if (tmpGraph.typeIntra < maxTypeIntra && (graph->nChannels == 0 || tmpGraph.typeIntra < graph->typeIntra)) {      tmpGraph.typeIntra += 1;      goto search;    }    tmpGraph.typeIntra = ngpus == 1 ? PATH_LOC : PATH_NVL;    if (system->nodes[NET].count > 0 && tmpGraph.typeInter < PATH_SYS && (graph->nChannels == 0 || tmpGraph.typeInter < graph->typeInter || tmpGraph.typeInter < PATH_PXB)) {      tmpGraph.typeInter += 1;      goto search;    }    tmpGraph.typeInter = PATH_PIX;     // Try a simpler tree    if (tmpGraph.pattern == NCCL_TOPO_PATTERN_SPLIT_TREE_LOOP) {      tmpGraph.pattern = NCCL_TOPO_PATTERN_SPLIT_TREE;      goto search;    }    if (tmpGraph.pattern == NCCL_TOPO_PATTERN_SPLIT_TREE) {      tmpGraph.pattern = NCCL_TOPO_PATTERN_TREE;      goto search;    }    tmpGraph.pattern = graph->pattern;     if (crossNic && tmpGraph.crossNic == 0) {      // Try again with crossNic if permitted      tmpGraph.crossNic = crossNic;      goto search;    }    tmpGraph.crossNic = 0;     // Decrease speed until we find a solution    if ((speedIndex < NSPEEDS-1) && (graph->nChannels == 0 || (speedArray[speedIndex+1]/graph->speedInter > .49))) {      tmpGraph.speedInter = tmpGraph.speedIntra = speedArray[++speedIndex];      goto search;    }    speedIndex = 0;    while (speedArray[speedIndex] > system->maxWidth && speedIndex < NSPEEDS-1) speedIndex++;    tmpGraph.speedIntra = tmpGraph.speedInter = speedArray[speedIndex];   } done:  // We have a solution. Start from that solution and move to pass 2.  if (pass == 1) {    time = -1;    memcpy(&tmpGraph, graph, sizeof(tmpGraph));    speedIndex = 0;    while (speedArray[speedIndex] > graph->speedInter && speedIndex < NSPEEDS-1) speedIndex++;    tmpGraph.speedIntra = tmpGraph.speedInter = speedArray[speedIndex];    tmpGraph.minChannels = graph->nChannels;    pass = 2;  }   // 3. See if we can increase speedIntra for trees (2 nodes or collnet)  if (pass == 2) {    if (time != 0 && graph->pattern != NCCL_TOPO_PATTERN_RING &&        tmpGraph.speedIntra == graph->speedIntra && tmpGraph.speedIntra < tmpGraph.speedInter*2 &&        speedIndex > 0) {      tmpGraph.speedIntra = speedArray[--speedIndex];      goto search;    }    time = -1;    memcpy(&tmpGraph, graph, sizeof(tmpGraph));  }   if (graph->nChannels == 0 && graph->collNet == 0) {    WARN("Could not find a path for pattern %d, falling back to simple order\n", graph->pattern);    for (int i=0; i<ngpus; i++) graph->intra[i] = system->nodes[GPU].nodes[i].gpu.rank;    graph->inter[0] = graph->inter[1] = 0;    graph->speedIntra = graph->speedInter = 0.1;    graph->typeIntra = graph->typeInter = PATH_SYS;    graph->nChannels = 1;  }   if (graph->speedIntra >= 25.0) {    int dupChannels = std::min(graph->nChannels*2, graph->maxChannels);    memcpy(graph->intra+graph->nChannels*ngpus, graph->intra, (dupChannels-graph->nChannels)*ngpus*sizeof(int));    memcpy(graph->inter+graph->nChannels*2,graph->inter, (dupChannels-graph->nChannels)*2*sizeof(int));    graph->speedIntra /= DIVUP(dupChannels, graph->nChannels);    graph->speedInter /= DIVUP(dupChannels, graph->nChannels);    graph->nChannels = dupChannels;  }  return ncclSuccess;}


然后开始搜索channel,对于ringGraph来说其实就是搜索出来一系列的环,每个rank对应这个环的一个节点,记录了环的prev和next,这里是一个回溯的过程,执行一次ncclTopoSearchRec就会得到一个环,执行一次ncclTopoSearchTryGpu看选择出来的下一个点能不能到达,执行一次ncclTopoSearchRecGpu用来找下一个GPU,接下来具体看下。


ncclResult_t ncclTopoSearchRec(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, struct ncclTopoGraph* saveGraph, int* time) {  int backToNet, backToFirstRank;  NCCLCHECK(ncclTopoSearchParams(system, graph->pattern, &backToNet, &backToFirstRank));  if (system->nodes[NET].count) {    // Start from NET    ncclTopoSearchRecNet(system, graph, saveGraph, backToNet, backToFirstRank, time);  } else {    // Intra-node only.    if (graph->nChannels == 0) {      // Try PCI order first      NCCLCHECK(ncclTopoSearchTryGpu(system, graph, saveGraph, 0, backToNet, backToFirstRank, FORCED_ORDER_PCI, time, -1, -1, 0));    } else {      // Also try to replay previous channel      int g;      NCCLCHECK(ncclTopoReplayGetGpu(system, graph, -1, &g));      NCCLCHECK(ncclTopoSearchTryGpu(system, graph, saveGraph, 0, backToNet, backToFirstRank, FORCED_ORDER_REPLAY, time, -1, -1, g));    }    if (graph->sameChannels == 0 || graph->nChannels == 0) {      // Finally, try all other possibilities unless we are forced to use the same channels      for (int g=0; g<system->nodes[GPU].count; g++) {        NCCLCHECK(ncclTopoSearchTryGpu(system, graph, saveGraph, 0, backToNet, backToFirstRank, 0, time, -1, -1, g));      }    }  }  return ncclSuccess;}


通过ncclTopoSearchParams设置backToNet和backToFirstRank参数,单机八卡ringGraph场景下这俩参数会分别设置为-1和7,此时nchannel为0,执行ncclTopoSearchTryGpu,强制为pci顺序,就是devid的顺序,从dev0开始。


ncclResult_t ncclTopoSearchParams(struct ncclTopoSystem* system, int pattern, int* backToNet, int* backToFirstRank) {  if (system->nodes[NET].count) {    if (pattern == NCCL_TOPO_PATTERN_RING) *backToNet = system->nodes[GPU].count-1;    else if (pattern == NCCL_TOPO_PATTERN_TREE) *backToNet = 0;    else *backToNet = 1;    if (pattern == NCCL_TOPO_PATTERN_SPLIT_TREE_LOOP) *backToFirstRank = system->nodes[GPU].count-1;    else *backToFirstRank = -1;  } else {    *backToNet = -1;    if (pattern == NCCL_TOPO_PATTERN_RING || pattern == NCCL_TOPO_PATTERN_SPLIT_TREE_LOOP) *backToFirstRank = system->nodes[GPU].count-1;    else *backToFirstRank = -1;  }  return ncclSuccess;}

然后执行ncclTopoSearchTryGpu,这里会判断下一个点能不能到达,因为type为-1,ncclTopoFollowPath会设置gpu为0号卡,直接执行ncclTopoSearchRecGpu,从0号卡开始搜,step为0。


ncclResult_t ncclTopoSearchTryGpu(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, struct ncclTopoGraph* saveGraph, int step, int backToNet, int backToFirstRank, int forcedOrder, int *time, int type, int index, int g) {  const uint64_t flag = 1ULL<<(graph->nChannels);  struct ncclTopoNode* gpu;  NCCLCHECK(ncclTopoFollowPath(system, graph, type, index, GPU, g, 1, &gpu));  if (gpu) {    gpu->used ^= flag;    NCCLCHECK(ncclTopoSearchRecGpu(system, graph, saveGraph, gpu, step, backToNet, backToFirstRank, forcedOrder, time));    gpu->used ^= flag;    NCCLCHECK(ncclTopoFollowPath(system, graph, type, index, GPU, g, -1, &gpu));  }  return ncclSuccess;}

ncclResult_t ncclTopoSearchRecGpu(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, struct ncclTopoGraph* saveGraph, struct ncclTopoNode* gpu, int step, int backToNet, int backToFirstRank, int forcedOrder, int *time) {  if ((*time) <= 0) return ncclSuccess;  (*time)--;   int ngpus = system->nodes[GPU].count;  if (step == ngpus) {    ...  }  graph->intra[graph->nChannels*ngpus+step] = gpu->gpu.rank;  int g = gpu - system->nodes[GPU].nodes;  if (step == backToNet) {    ...  } else if (step < system->nodes[GPU].count-1) {    // Go to next GPU    int next[NCCL_TOPO_MAX_NODES];    int count;    if (forcedOrder == FORCED_ORDER_PCI) { // Try the PCI order      next[0] = step+1;      count = 1;    } else if (forcedOrder == FORCED_ORDER_REPLAY) { // Try last channel order      NCCLCHECK(ncclTopoReplayGetGpu(system, graph, step, next));      count = 1;    } else { // Normal search      NCCLCHECK(ncclTopoSearchNextGpuSort(system, graph, gpu, next, &count, backToNet == -1 ? 0 : backToNet == step+1 ? 1 : -1 ));    }    for (int i=0; i<count; i++) {      NCCLCHECK(ncclTopoSearchTryGpu(system, graph, saveGraph, step+1, backToNet, backToFirstRank, forcedOrder, time, GPU, g, next[i]));    }  } else if (step == backToFirstRank) {    ...  } else {    // Next path    NCCLCHECK(ncclTopoSearchRecGpu(system, graph, saveGraph, gpu, ngpus, -1, -1, forcedOrder, time));  }  return ncclSuccess;}

然后看下ncclTopoSearchRecGpu,这里会选择下一个节点,先将0号卡节点写入到graph->intra的对应位置;由于当前step是0,因此会在xx行选择下一个GPU,next数组表示候选的GPU节点,由于forcedOrder == FORCED_ORDER_PCI,所以候选只有一个,即1号卡,然后对所有候选执行ncclTopoSearchTryGpu判断这一步是否可行并继续选择下一个节点。



然后回到ncclTopoSearchRec开始尝试判断是否可达1号卡,看下ncclTopoFollowPath,这个函数就是判断能否从type1的index1节点到达type2的index2节点,这里可以看到之前在选起点的时候type1为-1,因此直接将node设置为type2的index2就返回;这次我们要判断gpu0到gpu1是否可达,获取index1到index2的路径path,如果index1和index2的类型都是GPU那么speed就设置为graph->speedIntra,即搜索之前设置的条件,mult是函数的入参,表示需要在path上加还是减去speed,向下搜环的时候需要在path上减去speed,当回溯回去的时候需要将speed加回去,然后判断path的type是否大于之前设置的type,即graph->typeIntra,大于的话说明不可达,然后通过followPath将path上的边全都减去speed,如果有边剩下的带宽不够speed,那么通过rewind加回去,此时路径不可达;如果足够的话,则设置node为index2。

static ncclResult_t ncclTopoFollowPath(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, int type1, int index1, int type2, int index2, int mult, struct ncclTopoNode** node) {  // First handle easy cases  *node = system->nodes[type2].nodes+index2;  if (type1 == -1) return ncclSuccess;  struct ncclTopoNode* node1 = system->nodes[type1].nodes+index1;  struct ncclTopoLinkList* path = node1->paths[type2]+index2;  if (path->count == 0 ) return ncclSuccess;   // Now check link type  *node = NULL;  int intra = type1 == GPU && type2 == GPU;  float speed = intra ? graph->speedIntra : graph->speedInter;  int type = intra ? graph->typeIntra : graph->typeInter;   if (mult == 1 && (path->type > type)) return ncclSuccess;   speed *= mult;   // Check there is enough bandwidth on paths.  int step = 0;  NCCLCHECK(followPath(path, node1, path->count, speed, &step));  if (step < path->count) goto rewind;   // Enough bandwidth : return destination node.  graph->nHops += mult*path->count;  *node = system->nodes[type2].nodes+index2;  return ncclSuccess; rewind:  // Not enough bandwidth : rewind and exit.  NCCLCHECK(followPath(path, node1, step, -speed, &step));  return ncclSuccess;}

接着递归执行ncclTopoSearchRecGpu,重复上述过程,直到gpu7,这个时候graph->intra中的第一个环是[0,1,2,3,4,5,6,7],此时step为backToFirstRank,然后通过获取第一个gpu,即gpu0,然后继续执行ncclTopoFollowPath判断7到0是否可达,如果可达的话继续递归执行ncclTopoSearchRecGpu,此时step == ngpus,即搜索到了一个环,那会将现有的graph去更新最优的saveGraph,判断标准主要是看总的带宽,即环的数量乘以speedIntra;如果搜到的环的数量已经达到maxChannel了,则结束本次搜索,否则继续递归执行ncclTopoSearchRec搜索下一个环。


ncclResult_t ncclTopoSearchRecGpu(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, struct ncclTopoGraph* saveGraph, struct ncclTopoNode* gpu, int step, int backToNet, int backToFirstRank, int forcedOrder, int *time) {  if ((*time) <= 0) return ncclSuccess;  (*time)--;   int ngpus = system->nodes[GPU].count;  if (step == ngpus) {    // Determine whether we found a better solution or not    int copy = 0;    graph->nChannels++;    NCCLCHECK(ncclTopoCompareGraphs(graph, saveGraph, &copy));    if (copy) {      memcpy(saveGraph, graph, sizeof(struct ncclTopoGraph));      if (graph->nChannels == graph->maxChannels) *time = -1;    }    if (graph->nChannels < graph->maxChannels) {      NCCLCHECK(ncclTopoSearchRec(system, graph, saveGraph, time));    }    graph->nChannels--;    return ncclSuccess;  }  graph->intra[graph->nChannels*ngpus+step] = gpu->gpu.rank;  int g = gpu - system->nodes[GPU].nodes;  if (step == backToNet) {    ...  } else if (step < system->nodes[GPU].count-1) {    ...  } else if (step == backToFirstRank) {    // Find first GPU and loop back to it    int p;    NCCLCHECK(getGpuIndex(system, graph->intra[graph->nChannels*ngpus], &p));    struct ncclTopoNode* firstGpu;    NCCLCHECK(ncclTopoFollowPath(system, graph, GPU, g, GPU, p, 1, &firstGpu));    if (firstGpu) {      NCCLCHECK(ncclTopoSearchRecGpu(system, graph, saveGraph, firstGpu, step+1, backToNet, -1, forcedOrder, time));      NCCLCHECK(ncclTopoFollowPath(system, graph, GPU, g, GPU, p, -1, &firstGpu));    }  } else {    // Next path    NCCLCHECK(ncclTopoSearchRecGpu(system, graph, saveGraph, gpu, ngpus, -1, -1, forcedOrder, time));  }  return ncclSuccess;}

假设现在开始搜索下一个环,回到ncclTopoSearchRec,接下来会尝试复制刚刚的环,ncclTopoReplayGetGpu会获取上一个环的第step + 1个gpu,这里其实就是gpu0,然后继续执行ncclTopoSearchTryGpu,这里设置forcedOrder为FORCED_ORDER_REPLAY。


ncclResult_t ncclTopoSearchRec(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, struct ncclTopoGraph* saveGraph, int* time) {    {      // Also try to replay previous channel      int g;      NCCLCHECK(ncclTopoReplayGetGpu(system, graph, -1, &g));      NCCLCHECK(ncclTopoSearchTryGpu(system, graph, saveGraph, 0, backToNet, backToFirstRank, FORCED_ORDER_REPLAY, time, -1, -1, g));    }} ncclResult_t ncclTopoReplayGetGpu(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, int step, int* g) {  *g = -1;  if (graph->nChannels == 0) return ncclInternalError;  int ngpus = system->nodes[GPU].count;  int nextRank = graph->intra[(graph->nChannels-1)*ngpus+step+1];  for (int i=0; i<ngpus; i++) if (system->nodes[GPU].nodes[i].gpu.rank == nextRank) {    *g = i;    return ncclSuccess;  }  if (*g == -1) return ncclInternalError;  return ncclSuccess;}


然后FORCED_ORDER_REPLAY会在寻找下一个节点时通过ncclTopoReplayGetGpu获取上一个环对应step的gpu,因此就是一直在复制上一个环。


ncclResult_t ncclTopoSearchRecGpu(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, struct ncclTopoGraph* saveGraph, struct ncclTopoNode* gpu, int step, int backToNet, int backToFirstRank, int forcedOrder, int *time) {  ...  else if (step < system->nodes[GPU].count-1) {    // Go to next GPU    int next[NCCL_TOPO_MAX_NODES];    int count;    if (forcedOrder == FORCED_ORDER_PCI) { // Try the PCI order      next[0] = step+1;      count = 1;    } else if (forcedOrder == FORCED_ORDER_REPLAY) { // Try last channel order      NCCLCHECK(ncclTopoReplayGetGpu(system, graph, step, next));      count = 1;    } else { // Normal search      NCCLCHECK(ncclTopoSearchNextGpuSort(system, graph, gpu, next, &count, backToNet == -1 ? 0 : backToNet == step+1 ? 1 : -1 ));    }    for (int i=0; i<count; i++) {      NCCLCHECK(ncclTopoSearchTryGpu(system, graph, saveGraph, step+1, backToNet, backToFirstRank, forcedOrder, time, GPU, g, next[i]));    }  }   ...}


到这里就完成了第一次搜索,如前文所述,如果搜索出来的结果没有达到条件,就开始逐步降低条件继续搜索,接下来的过程比较类似,就不再赘述了。



然后看下多机场景下,比如两机十六卡场景,这个时候有网卡,所以ncclTopoSearchParams设置参数为backToFirstRank = -1,backToNet = 7,ncclTopoSearchRec直接执行ncclTopoSearchRecNet。


ncclResult_t ncclTopoSearchRec(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, struct ncclTopoGraph* saveGraph, int* time) {  int backToNet, backToFirstRank;  NCCLCHECK(ncclTopoSearchParams(system, graph->pattern, &backToNet, &backToFirstRank));  if (system->nodes[NET].count) {    // Start from NET    ncclTopoSearchRecNet(system, graph, saveGraph, backToNet, backToFirstRank, time);  }  ...}

ncclTopoSearchRecNet会搜索出来一个答案,这里会遍历每个网卡,尝试用每个网卡作为起点搜索环,首先是网卡0,将0写入到inter中第一个channel中,然后将网卡0的带宽减去speedInter,maxChannel减去1,然后后边过程和上述很像,会通过ncclTopoSearchTryGpu搜索出一个环。


ncclResult_t ncclTopoSearchRecNet(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, struct ncclTopoGraph* saveGraph, int backToNet, int backToFirstRank, int* time) {  const int speed = graph->speedInter;  for (int n=0; n<system->nodes[NET].count; n++) {    struct ncclTopoNode* net = system->nodes[NET].nodes+n;    struct ncclTopoNode* gpu;    if (graph->collNet && net->net.collSupport == 0) continue;    if (net->net.width < speed) continue;    if (net->net.maxChannels == 0) continue;     graph->inter[graph->nChannels*2] = net->id;    for (int i=0; i<system->nodes[NET].count; i++) {      if ((system->nodes[NET].nodes[i].net.asic == net->net.asic) &&          (system->nodes[NET].nodes[i].net.port == net->net.port)) {        system->nodes[NET].nodes[i].net.width -= speed;      }    }    net->net.maxChannels--;     // First try to replay the last channel    if (graph->nChannels > 0) {      int g;      NCCLCHECK(ncclTopoReplayGetGpu(system, graph, -1, &g));      NCCLCHECK(ncclTopoSearchTryGpu(system, graph, saveGraph, 0, backToNet, backToFirstRank, FORCED_ORDER_REPLAY, time, NET, n, g));    }    if (graph->nChannels == 0 || graph->sameChannels == 0) {      if (graph->nChannels == 0) {        // Always try the PCI order first to set a reference, but don't count in the timeout nor let it run for long        int t = 1 << 10;        NCCLCHECK(ncclTopoSearchTryGpu(system, graph, saveGraph, 0, backToNet, backToFirstRank, FORCED_ORDER_PCI, &t, NET, n, 0));        if (t == -1) *time = -1;      }      ...  }  return ncclSuccess;}


ncclTopoSearchTryGpu还是会调用ncclTopoSearchRecGpu,当没有遍历完所有GPU节点时,仍然通过递归执行ncclTopoSearchRecGpu来填充graph->intra,最后遍历所有GPU之后step等于7,即backToNet,这里首先拿出来起始网卡,即网卡0,如果搜索参数支持crossNic的话就选一个合法的网卡即可,如果不支持的话就判断网卡0是否合法,合法的话将网卡0填充到graph->inter,一个环就搜索完成了。这里有一个小的疑惑点,在将出口网卡选择好后,并没有将该网卡的带宽减去speed。


ncclResult_t ncclTopoSearchRecGpu(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, struct ncclTopoGraph* saveGraph, struct ncclTopoNode* gpu, int step, int backToNet, int backToFirstRank, int forcedOrder, int *time) {  if ((*time) <= 0) return ncclSuccess;  (*time)--;   int ngpus = system->nodes[GPU].count;  if (step == ngpus) {    // Determine whether we found a better solution or not    int copy = 0;    graph->nChannels++;    NCCLCHECK(ncclTopoCompareGraphs(graph, saveGraph, &copy));    if (copy) {      memcpy(saveGraph, graph, sizeof(struct ncclTopoGraph));      if (graph->nChannels == graph->maxChannels) *time = -1;    }    if (graph->nChannels < graph->maxChannels) {      NCCLCHECK(ncclTopoSearchRec(system, graph, saveGraph, time));    }    graph->nChannels--;    return ncclSuccess;  }  graph->intra[graph->nChannels*ngpus+step] = gpu->gpu.rank;  int g = gpu - system->nodes[GPU].nodes;  if (step == backToNet) {    // first get back to NIC    if (system->nodes[NET].count) {      int startNetIndex;      NCCLCHECK(getNetIndex(system, graph->inter[graph->nChannels*2], &startNetIndex));      struct ncclTopoNode* startNet = system->nodes[NET].nodes+startNetIndex;      for (int n=0; n<system->nodes[NET].count; n++) {        struct ncclTopoNode* net = system->nodes[NET].nodes+n;        if (graph->pattern == NCCL_TOPO_PATTERN_TREE && net->id != startNet->id) continue; // Trees are symmetric        if (graph->crossNic != 1 && (net->net.asic != startNet->net.asic || net->net.port != startNet->net.port)) continue;        NCCLCHECK(ncclTopoFollowPath(system, graph, GPU, g, NET, n, 1, &net));        if (net) {          graph->inter[graph->nChannels*2+1] = net->id;          NCCLCHECK(ncclTopoSearchRecGpu(system, graph, saveGraph, gpu, step, -1, backToFirstRank, forcedOrder, time));          NCCLCHECK(ncclTopoFollowPath(system, graph, GPU, g, NET, n, -1, &net));        }      }    }  } else if (step < system->nodes[GPU].count-1) {    // Go to next GPU    int next[NCCL_TOPO_MAX_NODES];    int count;    if (forcedOrder == FORCED_ORDER_PCI) { // Try the PCI order      next[0] = step+1;      count = 1;    } else if (forcedOrder == FORCED_ORDER_REPLAY) { // Try last channel order      NCCLCHECK(ncclTopoReplayGetGpu(system, graph, step, next));      count = 1;    } else { // Normal search      NCCLCHECK(ncclTopoSearchNextGpuSort(system, graph, gpu, next, &count, backToNet == -1 ? 0 : backToNet == step+1 ? 1 : -1 ));    }    for (int i=0; i<count; i++) {      NCCLCHECK(ncclTopoSearchTryGpu(system, graph, saveGraph, step+1, backToNet, backToFirstRank, forcedOrder, time, GPU, g, next[i]));    }  } else if (step == backToFirstRank) {    ...  } else {    // Next path    NCCLCHECK(ncclTopoSearchRecGpu(system, graph, saveGraph, gpu, ngpus, -1, -1, forcedOrder, time));  }  return ncclSuccess;}


回到ncclTopoSearchRecNet,接下来会尝试复制刚刚搜索出来的环,当搜索出一个答案后,回到第一次ncclTopoSearchRecNet,接下来会尝试从离网卡0最近的GPU开始搜索,而不是从GPU0开始,假设为GPUn,这里会先判断GPUn到PCIe switch的双向带宽是否还有空闲,如果有空闲的话才从GPUn开始搜索。但是和这里的注释表述不太相符,注释的意思是说不会将一个GPU既用来发送,又用来接收(说这种情况会影响带宽,这一点比较疑惑)。


ncclResult_t ncclTopoSearchRecNet(struct ncclTopoSystem* system, struct ncclTopoGraph* graph, struct ncclTopoGraph* saveGraph, int backToNet, int backToFirstRank, int* time) {  const int speed = graph->speedInter;  for (int n=0; n<system->nodes[NET].count; n++) {    ...      // Then try the most local GPUs      float maxWidth = 0;      int minHops = 0xfffffff;      struct ncclTopoLinkList* paths = net->paths[GPU];      for (int g=0; g<system->nodes[GPU].count; g++) {        if (paths[g].width > maxWidth) {          maxWidth = paths[g].width;          minHops = paths[g].count;        } else if (paths[g].width == maxWidth && paths[g].count < minHops) {          minHops = paths[g].count;        }      }      if (maxWidth >= speed) {        // In the first loop, avoid using GPUs in both directions between channels (one channel        // sending from that GPU and one channel receiving to that GPU), since that usually leads        // to lower BW.        for (int tryGpuBidir=0; tryGpuBidir<2; tryGpuBidir++) {          for (int g=0; g<system->nodes[GPU].count; g++) {            if (paths[g].width == maxWidth && paths[g].count == minHops) {              gpu = system->nodes[GPU].nodes+g;              int gpuUsed = gpuPciWidth(gpu) > 0 ? 0 : 1;              if (tryGpuBidir == gpuUsed) {                NCCLCHECK(ncclTopoSearchTryGpu(system, graph, saveGraph, 0, backToNet, backToFirstRank, 0, time, NET, n, g));              }            }          }        }      }    }     net->net.maxChannels++;    for (int i=0; i<system->nodes[NET].count; i++) {      if ((system->nodes[NET].nodes[i].net.asic == net->net.asic) &&          (system->nodes[NET].nodes[i].net.port == net->net.port)) {        system->nodes[NET].nodes[i].net.width += speed;      }    }  }  return ncclSuccess;}


到这里就完成了channel的搜索。总结一下,本节就是基于机器拓扑,搜索出一组channel用于数据的通信,并记录到ncclTopoGraph。


(本文经授权后由OneFlow发布。原文:https://blog.csdn.net/KIDGIN7439/article/details/128074716)
